The iP 1515-RX integrates advanced microcontroller power management with elite RX Series surge protection and filtration. This professional-grade unit allows for precise internet or intranet control of individual AC receptacles via Ethernet or RS232 connections. Six receptacles are grouped into three independent Power Pods, enabling discrete remote cycling and sequencing for sensitive audio-visual equipment. The on-board web server provides an intuitive graphic interface for immediate setup, monitoring, and administrative control. High-performance RX technology limits ground line surges to 0.50 volts, effectively safeguarding digital processors and DSPs from operational faults. Additionally, the unit features a local fail-safe manual override to ensure continuous operation during network interruptions. This solution is ideal for reducing energy costs and protecting high-value electronics in professional installations.
| Current Rating | 15 Amps |
| Operating Voltage | 120 VAC |
| Number of Outlets | 6 (3 Addressable Pods) |
| Surge Protection | 1,020 Joules |
| AC Line Filtration | 60dB to 80dB @ 30MHz |
| Maximum Ground Surge | 0.50 Volts |
| Communication Protocols | TCP/IP, RS232, SNMP |
| Chassis Format | 1U Rack Mount |
