The EKX-15 delivers high-performance audio in a compact, two-way passive loudspeaker design. It features a 15-inch EVS-15M low-frequency transducer paired with a 1-inch DH-1M titanium compression driver. Custom-designed Signal Synchronized Transducers waveguide provides precise and consistent coverage for your entire audience. Professional-grade hardware includes eight M10 threaded mounting points for versatile installation or suspension options. The lightweight 15 mm plywood enclosure is finished with a durable EVCoat to withstand rigorous touring environments. Large 18 AWG steel grilles protect internal components while maintaining a sleek, professional aesthetic. This loudspeaker is an ideal choice for portable sound reinforcement and fixed installation applications.
| Transducer Type | 15-inch EVS-15M |
| High Frequency Driver | 1-inch DH-1M Titanium Compression Driver |
| Power Handling | 400 Watts Continuous, 1600 Watts Peak |
| Maximum SPL | 132 dB |
| Frequency Response (-3 dB) | 75 Hz – 18 kHz |
| Nominal Impedance | 8 Ohms |
| Coverage Pattern | 90° x 60° |
| Enclosure Material | 15 mm Plywood with EVCoat |
| Grille Material | 18 AWG Steel with Powdercoat |
| Mounting Points | (8) M10 Threaded Points |
| Crossover Frequency | 1.6 kHz |
