This powerful and lightweight fixture delivers 17,325 lumens of output with an 18:1 zoom range. It maintains a flat field of focus from a narrow 3.5° beam to a wide 57.7° beam. Equipped with a variable CMY color mixing system, it produces true reds and vibrant hues. The fixture includes a color wheel with CRI and CTB filters, static and rotating gobo wheels, a five-facet prism, iris, and frost. Its compact design and excellent dimming performance make it suitable for diverse short- and long-throw applications. Control options include DMX, RDM, sACN, Art-Net, and CRMX for comprehensive flexibility. Advanced features like 65,000 PWM ensure compatibility with high-speed cameras, enhancing professional production value.
| Light Source | 1 LED (CW) 520 W |
| Color Temperature | 6462 K |
| Front Lens Diameter | 5.71 inches (145 mm) |
| CRI | 72.2 (90 with CRI filter) |
| Zoom Range | 3.5° to 57.7° |
| Output Lumens | 17,325 |
| Illuminance (3.5°) | 93,084 lux @ 16.4 feet (5 m) |
| Illuminance (57.7°) | 1,135 lux @ 16.4 feet (5 m) |
| PWM Selectable | 600Hz, 1500Hz, 2000Hz, 65000Hz |
| Pan Movement | 540°, 360°, 180° |
| Tilt Movement | 270°, 180°, 90° |
| Color System | CMY mixing, 7 colors + white (including CRI and CTB filters) |
| Rotating Gobo Wheel | 9 metal gobos + open, continuous scroll at variable speeds |
| Rotating Gobo Size | 0.94 inches (24mm) outside, 0.55 inches (14mm) image, 0.04 inches (1.1mm) max. thickness |
| Static Gobo Wheel | 7 gobos (1 metal + 6 glass) + open, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds |
| Prism | 5-facet, motorized, rotating |
| Frost | Motorized |
| Iris | Motorized |
| Dimmer | Electronic, 16-bit |
| Strobe Rate | 0 to 25 Hz |
| Control Protocols | DMX, CRMX, sACN, Art-Net, RDM |
| DMX Channels | 22 or 29 |
| Input Voltage | 100-240 VAC, 50/60 Hz |
| Power Consumption | 554 W, 4.64 A @ 120 V, 60 Hz |
| Battery Type | Lithium Ion (for display screen backup) |
| Battery Life | 1 hour |
| IP Rating | IP20 (dry location) |
| Operating Temperature | -4 °F to 113 °F (-20 °C to 45 °C) |
| Housing Material | Aluminum die-cast, High-impact flame-retardant polymer, Steel |
| Power Connection | Edison plug to Seetronic Powerkon IP65 |
| Data Connectors | 3- and 5-pin IP65 XLR, Seetronic etherCON |
| Signal Cable Length | 5 feet (1.5 m) |
