The CHAUVET Professional Color STRIKE M is a robust IP65-rated motorized strobe and wash fixture engineered for demanding outdoor and indoor environments. It features two ultra-bright white light tube elements enveloped by a dynamic color-mixing, pixel-mappable face. This versatile unit provides a 180-degree tilt range, allowing for precise projection of intense, saturated colors across any stage or venue. Its durable IP65 casing ensures protection against environmental elements, while dual omega-bracket attachments offer flexible horizontal or vertical mounting. Advanced control options include DMX, Art-Net, and sACN, alongside multiple programming personalities for intricate or simple setups. The fixture boasts 14 controllable RGB LED sections and 28 white strobe LED sections, all pixel-mappable for sophisticated visual effects. Integrated alignment pins guarantee perfectly straight linear arrays for creating impressive, large-scale lighting installations.
| Light Source (Tri-color) | 896 SMD 5050 LEDs, 0.784 W each, 50,000 hours life expectancy |
| Light Source (CW) | 432 LEDs, 1.56 W each, 5861K, 50,000 hours life expectancy |
| Color Temperature | 7757 K |
| CRI | 90.3 |
| Beam Angle (Combined) | 98° x 57° |
| Field Angle (Combined) | 146° x 122° |
| Lumens (Combined) | 71,620 |
| Illuminance (Combined) | 1591 lux @ 5 m |
| Selectable PWM | 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz |
| Tilt Range | 0° to 180° |
| Strobe Rate | 0 to 30 Hz |
| Dim Modes | 4 |
| Exterior Color | Black |
| Housing Material | Magnesium alloy |
| Power Connection | Seetronic Powerkon IP65 |
| Data Connectors | 5-pin IP65 XLR, Seetronic etherCON IP65 |
| Power Cable Length | 5 ft |
| Control Protocol | Art-Net, DMX, RDM, sACN |
| DMX Channels | 8, 11, 13, 24, 30, 47, 68, 74 or 97 |
| Input Voltage | 100 to 240 VAC, 50/60 Hz |
| Max Power Consumption | 740 W @ 120 V, 60 Hz |
| IP Rating | IP65, temporary outdoor/wet use |
| Ambient Temperature | 14 °F to 113 °F |
