Designed as the brightest outdoor-rated LED ellipsoidal fixture, this unit delivers an exceptionally even field of high CRI light for superior gobo projection with extended reach for professional applications. Compatibility with standard Ovation lenses and an integrated GR-1 Gobo Rotator power/data port streamline operation. A dedicated Focus Mode button provides convenient adjustments. The 3000K warm white output features smooth 16-bit dimming across selectable curves. Selectable PWM further guarantees brilliant performance for both live events and camera work. This IP65-rated fixture is ideal for seasonal indoor or outdoor use.
| Light Source | 1 LED (WW) 400W, 50,000 hours life expectancy |
| Color Temperature (at full) | 3200 K |
| CRI | 97.8 |
| IP Rating | IP65, temporary outdoor/wet use |
| Housing Material | Aluminum die-cast |
| Control Protocol | DMX, RDM |
| DMX Channels | 2, 3, 4, or 7 |
| Input Voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Power Cable Length | 5 feet (1.5 m) |
| Noise Level (Idle) | 21.1 dB(A) at 3.28 feet (1 m) |
| Selectable PWM Frequencies | 600 Hz, 1.2 kHz, 2 kHz, 4 kHz, 6 kHz, 25 kHz |
| Dimming Modes/Curves | 4 modes, 4 curves (18-bit and 8-bit) |
| Gobo Size (Type A) | 3.94 inches (100 mm) outside, 2.95 inches (75 mm) image, 0.098 inches (2.5 mm) max thickness |
| Gobo Size (Type B) | 3.39 inches (86 mm) outside, 2.54 inches (64.5 mm) image, 0.098 inches (2.5 mm) max thickness |
| Accessory Holder/Gel Frame Size (5° lens) | 14 inches (356 mm) |
| Power Linking (120V) | 3 units |
| Certifications | CE, MET, UKCA, RoHS |
| Power and Current (120V, 60Hz) | 428 W, 3.57 A |
