The Stradale Profile represents the pinnacle of scalability within the Ayrton Ultimate series as a high-performance, ultra-compact luminaire. Engineered for extreme miniaturization, it delivers a powerful 20,000-lumen output from a specialized 330W LED engine. Its IP65 rating ensures reliable operation in both indoor and outdoor environments regardless of weather conditions. The proprietary 13-lens optical system provides a versatile 13:1 zoom ratio, ranging from a tight 4° beam to a wide 52° wash. Creative control is expanded through infinite continuous rotation on both pan and tilt axes for dynamic movement. A sophisticated CMY progressive gradient system allows for seamless color mixing and impeccable uniformity across the beam. This fixture sets a new industry benchmark for weight and power, tipping the scales at just 51.8 pounds.
| Material | Die-cast aluminum, steel, and fire-retardant ABS PC (estimated): true |
| Light Engine | 330W High-Efficiency White LED Module |
| Luminous Output | 20,000 Lumens |
| Color Temperature | 6500 K |
| Zoom Range | 4° to 52° (13:1 Ratio) |
| IP Rating | IP65 (Dust-tight and Water-resistant) |
| Front Lens Diameter | 5.51 in |
| Movement | Infinite continuous rotation on Pan and Tilt axes |
| Color Mixing | CMY Progressive Gradient System with Variable CTO |
| Gobo System | 9 Rotating and 10 Fixed High-Definition Glass Gobos |
